Alura 4500 Windows
Your vision comes to life with our high-performance designs
The beauty of a window is in the way it expands our world, bringing light into a room. The larger the opening, the better! Many people think of a window as glass; the crucial role of the profile – the bridge between the wall and the glass – is easy to overlook. Surrounding the glass, these precision-engineered profiles insulate from the elements and support smooth operation, creating high-performance windows and doors that elevate your vision for years.
Top performance, intelligent design, timeless style
Our windows are engineered to perform. They are beautiful, durable, energy efficient and available in an extensive variety of styles, colors and configurations. uPVC delivers where others fail An Alura window resists fading or corrosion. Our proprietary unplasticized polyvinyl chloride (uPVC) formulation and extrusion process result in superior profiles that outlast and outperform materials such as aluminum or wood. Plus, uPVC is a natural insulator. It resists heat loss in winter and heat gain in summer. Less stress on the environment Our windows offer long service life and excellent thermal performance that minimize energy use.
Alura 4500 Series
This series produces some of North America’s highest performing window units. This versatile design can be
configured into tilt-turn and fixed windows.
System Features
Fusion-welded corners In addition to the benefits of uPVCs thermal properties, fusion-welded corners greatly reduce leakage potential and the need for costly sill pans/pan flashing systems.
Steel reinforcement our sophisticated multi-chambered designs accommodate steel reinforcement that allows larger windows to remain structurally sound. This, in turn, provides greater daylight openings and brighter interior designs.
Compression-seal technology When the wind is blowing strong and rain is pouring down, compression seals are optimizing the air and water performance of Alura windows.
Multiple locking points Multi-point locking hardware assures consistent compression on the seals all around the perimeter of the sash and frame for further performance enhancements and improved security
High-definition finish Only occasional cleaning with soap and water is needed to keep the surfaces looking like new, even years after installation.
For those who want the best
System Description
Performance Summary
Types
Fixed, tilt-turn (dual action), hopper and awning windows. Matching doors also available.
Material
Cadmium- and lead-free RAU-PVC
Sealing system
Twin compression seals
System depth
3 1/4 in (82.5 mm) typical residential; 2 3/8 in (60 mm) commercial applications
Frame / sash overlap
5/16 in (8 mm)
Hardware axis
1/2 in (13 mm)
Max. glass thickness
1 3/8 in (35 mm)
Sightlines frame / sash
4.724 to 6.535 in (120 to 166 mm)
ASTM E90 acoustical (STC)
up to 43 dB; OITC 34
U-values
Down to 0.17*
Structural tests (NAFS)
Tilt-turn: up to CW-PG90
Fixed: up to CW-PG75
Hopper: up to LC-PG75
ASTM & TAS
Impact resistant DP 65 (HVHZ)
The secret is in the formulation
Proprietary uPVC formulation includes above-average quantities of TiO2 stabilizers and impact
modifiers to protect against fading from solar radiation. When put through five years of weather testing in Arizona, and performed better than standard vinyl.
In addition, 4500 Series windows use a higher than average surface gloss, enhancing the ability of the windows and doors to repel dirt and retain their color for many years.
The all-around talent
Save energy with better thermal performance
Reducing energy usage is important, not just for the occupant’s wallet but also on a larger scale when it comes to sustainable building. Lower energy consumption with a good conscience – whether it’s cold or hot outside.
Ensure peace and quiet with a view on mute
Noise is disturbing and over time, it is even unhealthy. Increase occupants’ feeling of well-being with previously unattained values in noise protection.
Minimize maintenance with ease of operation and ease of cleaning
Thanks to a high-quality, high-definition finish (HDF), smudges can be quickly and easily removed using conventional detergents. As far as maintenance, the occasional application of a quality lubricant to the
moving parts, such as hinges and lock mechanisms, is all that is needed.
​
The sealing technology assures optimal closing pressure. Due to advanced engineering and close cooperation with hardware suppliers, window and door operation is smooth and easy. Reduce maintenance and cleaning effort to a minimum.
Trust high levels of safety with superior security features
In combination with the appropriate hardware, EuroDesign 4500 windows and doors enhance security with multiple locking points, fusion-welded corners and steel-reinforced, multi-chambered design. Enjoy the security you are looking for.
